OHM D SERIES - AMPLIFIER DSP
Powerful Class D amplifiers with internal DSP, FIR Filters, 2 x Ethernet connectors
- 4 Channel Class D Digital power amplifier
- Mini 1U size,convenient for Touring Applications
- Suit for Top speaker, full range speaker,Line array speaker
- Work Under 2Ω steadily !
- Precise and Reasonable circuit structure
- Bring supper reliable sound
- Bridge-mode operation
- Original Neutrik XLR*/Speakon connectors
- Temperature protection;Over current protection;Short circuit protection built-in
High performance 2-channel amplifier DSP
OHM-D2250
Amplifier 2 channel with DSP, Ethernet
Stereo Mode: 8Ω - 2*2500
Stereo Mode: 4Ω - 2*4800
Stereo Mode: 2Ω - 2*6800
Frequency Response: 20Hz-20kHz,+0/-1dB
Total Harmonic Distortion (THD): <0.5%,20Hz-20kHz
Damping Factor (8Ω): >5000 @ 20-200 Hz
Signal-to-Noise Ratio: >100dB)
Size/ Weight: 482x44x480mm/ 13KG
OHM-D2300
Amplifier 2 channel with DSP, Ethernet
Stereo Mode: 8Ω - 2*3000
Stereo Mode: 4Ω - 2*5100
Stereo Mode: 2Ω - 2*7140
Frequency Response: 20Hz-20kHz,+0/-1dB
Total Harmonic Distortion (THD): <0.5%,20Hz-20kHz
Damping Factor (8Ω): >5000 @ 20-200 Hz
Signal-to-Noise Ratio: >100dB)
Size/ Weight: 482x44x470mm/ 13KG
OHM-D2350
Amplifier 2 channel with DSP, Ethernet
Stereo Mode: 8Ω - 2*3500
Stereo Mode: 4Ω - 2*6500
Stereo Mode: 2Ω - 2*7500
Frequency Response: 20Hz-20kHz,+0/-1dB
Total Harmonic Distortion (THD): <0.5%,20Hz-20kHz
Damping Factor (8Ω): >5000 @ 20-200 Hz
Signal-to-Noise Ratio: >100dB)
Size/ Weight: 482x44x470mm/ 13KG
OHM-D2420
Amplifier 2 channel with DSP, Ethernet
Stereo Mode: 8Ω - 2*4200
Stereo Mode: 4Ω - 2*7800
Stereo Mode: 2Ω - 2*8500
Frequency Response: 20Hz-20kHz,+0/-1dB
Total Harmonic Distortion (THD): <0.5%,20Hz-20kHz
Damping Factor (8Ω): >5000 @ 20-200 Hz
Signal-to-Noise Ratio: >100dB)
Size/ Weight: 482x44x470mm/ 13KG
High performance 4-channel amplifier DSP
OHM-D4100
Amplifier 4 channel with DSP, Ethernet
Stereo Mode: 8Ω - 4*1000
Stereo Mode: 4Ω - 4*1700
Stereo Mode: 2Ω - 4*2890
Frequency Response: 20Hz-20kHz,+0/-1dB
Total Harmonic Distortion (THD): <0.5%,20Hz-20kHz
Damping Factor (8Ω): >5000 @ 20-200 Hz
Signal-to-Noise Ratio: >100dB)
Size/ Weight: 482x44x480mm/ 13KG
OHM-D4130
Amplifier 4 channel with DSP, Ethernet
Stereo Mode: 8Ω - 4*1300
Stereo Mode: 4Ω - 4*2400
Stereo Mode: 2Ω - 4*3000
Frequency Response: 20Hz-20kHz,+0/-1dB
Total Harmonic Distortion (THD): <0.5%,20Hz-20kHz
Damping Factor (8Ω): >5000 @ 20-200 Hz
Signal-to-Noise Ratio: >100dB)
Size/ Weight: 482x44x480mm/ 13KG
OHM-D4160
Amplifier 4 channel with DSP, Ethernet
Stereo Mode: 8Ω - 4*1600
Stereo Mode: 4Ω - 4*2600
Stereo Mode: 2Ω - 4*3500
Frequency Response: 20Hz-20kHz,+0/-1dB
Total Harmonic Distortion (THD): <0.5%,20Hz-20kHz
Damping Factor (8Ω): >5000 @ 20-200 Hz
Signal-to-Noise Ratio: >100dB)
Size/ Weight: 482x44x470mm/ 14KG
OHM-D4200
Amplifier 4 channel with DSP, Ethernet
Stereo Mode: 8Ω - 4*2000
Stereo Mode: 4Ω - 4*3400
Stereo Mode: 2Ω - 4*4760
Frequency Response: 20Hz-20kHz,+0/-1dB
Total Harmonic Distortion (THD): <0.5%,20Hz-20kHz
Damping Factor (8Ω): >5000 @ 20-200 Hz
Signal-to-Noise Ratio: >100dB)
Size/ Weight: 482x44x470mm/ 14KG
OHM-D4300
Amplifier 4 channel with DSP, Ethernet
Stereo Mode: 8Ω - 4*3000
Stereo Mode: 4Ω - 4*5000
Stereo Mode: 2Ω - 4*6860
Frequency Response: 20Hz-20kHz,+0/-1dB
Total Harmonic Distortion (THD): <0.5%,20Hz-20kHz
Damping Factor (8Ω): >5000 @ 20-200 Hz
Signal-to-Noise Ratio: >100dB)
Size/ Weight: 482x44x470mm/ 14KG
OHMControl Remote Operation Software
STABLE DOWN TO 2 OHMS
Huge output power and stable down to 2 Ohms
The power output figures of DP-F series are staggering. The rated power outputs are measured at THD = 1%, continuous sinusoidal 1 KHz with each channel working simultaneously.
DP-F amps are also stable down to 2 Ohms. This allows for multiple 8 Ω or 16 Ω speakers to be driven with extreme power.
ETHERNET X 2
Control is via the Ethernet network connectors on the front.
With the supplied control software all parameters can be edited and all performance functions can be remotely monitored.
